Description
The Arc Pro CNC Router Table from Arclight Dynamics is available in 5×5 and 4×4 models. Our industrial strength CNC router tables will increase your productivity, improve your quality of work, enhance your ability to deliver projects on time and under budget.
In minutes you can set up the machine to design and cut parts, allowing the operator to complete other projects.
An Arclight Dynamics CNC router table will be, hands down, the best investment for your shop and cost less than a part time employee. In addition, your new CNC Router Table will come with a full team of Arclight support technicians (Arc Angels) to assist you every step of the way.
Each Arc Pro CNC Router Table comes will an industry leading limited lifetime warranty on the table frame, 3 year warranty on its controller and motion control system, and a 1 year warranty on the dedicated computer.
We proudly build our CNC Router Tables in the United States. We believe strongly in honest business transparency without hidden fees or recurring charges.
Key features of Arclight Dynamics tables that allow for effective CNC routing:
- 620 oz motors on each side of our high-clearance gantry provide over 3000 oz of effective torque.
- A single 620 oz motor provides 1800 oz of torque for the x axis alone.
- Thick aluminum extrusion gantry resists cutting forces.
- Overbuilt z axis w/ 7″ of travel that can handle a 2 1/4 HP router.
- Extra gantry clearance allows you to mount a table surface on top of the slats and still have 3″ clearance (more clearance is available if you chose to remove the slats).
- Three point bearing blocks hold the gantry tight to the side rails and prevent upward motion.
Standard Performance Features
Our steel and aluminum CNC frame generally weigh 2 to 4 times as much as our nearest competitor’s table. This weight combined with an engineered steel substructure and redundant cross bracing minimizes vibration and noise, which increases cut quality and table accuracy.
The Arc Pro gantry is driven on both sides with two powerful motors. This dual drive eliminates gantry flex which allows for fast, clean, accurate cutting. This means:
- Cleaner cuts (less clean up means more profit)
- More accurate cuts (less waste of material and time)
- Faster cut times (faster positioning between cuts reduces cut time dramatically)
- Uses precision bearings for minimal resistance and low maintenance
- Hiwin® 20 mm precision linear guide rails
- Provides super smooth motion for unmatched cut quality
- Dual seals and scrapers maintain a clean guideway for longer life and the best protection available
With advanced features like corner and hole slow downs, reverse cut directions, contouring, and additional option inputs, you will achieve superior cut quality through simple programming that is easy to understand and use.
The Arclight routing system allows for complete control of the cut: pause, fast forward, rewind and re-cut any part, virtually eliminating materials waste. Our Computer Numerated Control (CNC) system provides a simple ‘click of the button’ control and operation or can operate with complex sophistication using personally generated g-code. CNC features that our competitors just don’t offer.
Industrial Linux software for reliability and ease of use.
Specifications
For the Arc Pro 6000X 5×5 CNC Router Table
- Cutting envelope: 60” x 60” x 5.5" (standard gantry)
- Cutting envelope: 60” x 60” x 8.5" (high clearance gantry)
- Overall dimensions: 87.5” x 80" x 58”
- Frame: Hybrid Steel and Aircraft Grade Aluminum
- 1.5" Spoilboard Included
- Dimensions at base: 73.5” x 79.5"
- Table Power: 110V / 15-20A
- Overall Weight: 825 pounds
- Positioning Accuracy: .001"
Testimonials
Learn more about how Classic Car Studios uses their Arclight Dynamics CNC Plasma Table
See how Barbie the Welder uses her table to grow her business.
FAQ
With our systems you will receive the CNC Table with a mini computer pre-installed with all the software you need to set up pocket and contour routing operations. Our standard software has no recurring licenses or fees. Includes a 2.25 horsepower variable speed router that accepts 1/4″ or 1/2″ collet bits, dust collection shroud and sacraficial spoil board. The dust collection shroud with 3″ opening is ready to integrate with your dust collection system. Router bits are sold seperatly.
The CNC Router can cut wood, acrylic, aluminum, brass, plastic, foam, composites, phenolic and other solid materials.
All tables come with lifetime support that follows the table to any owner. Our staff of expert full time technical support agents are available Monday-Friday 7:30 am to 4:00 pm PST. They can be reached via email or phone. Occasionally you will have to leave a message, but they return all calls in the order received as we see every call through to resolution. Our support team also monitors our table owners group on Facebook Arclight Dynamics Users Support Forum. This is a gated, owners-only group that is an invaluable resource for new and experienced operators.
Email: support@arclightcnc.com | Phone: 866-222-2154 (option 2).
We offer several options for learning the machine. Every table comes with a comprehensive operation manual that walks you through setup, maintenance, operation and every accessory. In addition to this manual, there are extensive video training modules on every table and on our website. Also, we offer lifetime technical support via phone, email, video conference and remote desktop. Additional training options include in house and on-site training. There may be an additional cost for these services.
Most users are able to get started cutting right away with basic preparations including power and dust collection. It is a simple three step process: CAD, CAM and Cut. We will provide you with training resources, references and software ahead of your tables delivery. Also, live technical support is available to help you get up and running as fast as possible.
Our CNC Systems shipped 98% assembled with all the components loaded and secured to the top of the table. We ship partial load LTL, fully insured with a driver no-touch policy. The system is not trans-loaded, moved or otherwise disturbed until it arrives at your location. Offloading will require a forklift or similar machine with extensions to facilitate front or side offload. In some cases where a forklift is not available a tilt-bed roll-off style tow truck can be hired to assist with offloading. All tables are equipped with caster wheels that can be lowered to aid with rolling the table off the truck.
Limited Lifetime Warranty on the table, 3-Year Comprehensive Warranty on the Controller and Motors. 2-Year for other electronics and a 1-Year Computer Warranty.
You have the option of purchasing a 1 or 2 year Extended Warranty for any Arclight Dynamics CNC Router Table.
All tables ship fully tested and 98% assembled, making it easy to cut your first masterpiece. An initial training session and lifetime support are included with every table.
