Design2Fab^® sheet metal layout software makes it easy to create HVAC duct, mechanical, kitchen, industrial, roofing, and other specialty fitting layouts. Engineered to dramatically reduce the time it takes to develop and lay out flat patterns, Design2Fab gives sheet metal fabricators, HVAC shops, and MEP contractors the ability to create complex custom fitting layouts in minutes, rather than hours. Design2Fab also helps ensure perfect fit-up when installing parts in the field, contributing to increased productivity and lower operating costs – so you’ll be able to accomplish more, while increasing profitability.

$950.00

Grand total: See in cart

Description
Additional information

Description

Ease of use
- Even a beginner to the sheet metal trade can immediately start making fittings with a complete range of templates.
Flexibility
- Export patterns to DXF for automated cutting, export to a label printer for easy fit-up.
ProNest integration
- Design2Fab is the only software offering integration to Hypertherm ProNest® nesting software, delivering SureCut™ technology.
Unlimited technical support
- Access to Hypertherm’s tech service engineers is included at no additional charge.
The Hypertherm difference
- Brought to you by the cutting experts with 50 years of experience and more than 160 cutting technology related patents to their name.

System Requirements

For Design2fab software by Hypertherm

Learn More

Watch and learn more about Hypertherm Design2fab Software.

Quick Design2fab overview video.
